Four filters, one defensible shortlist

Samsung LED Quick Select

Organize commercial luminaires by luminous flux, mounting method, IP rating and dimming interface. The dashboard is a screening tool: final selection still depends on the exact photometric file, thermal conditions and project approvals.

Lighting product selection dashboard
01

Luminous flux

Bracket maintained illuminance before selecting a nominal lumen package.

  • 2,000–4,000 lm for smaller occupied zones
  • 4,000–8,000 lm for larger commercial bays
  • 12,000 lm and above for high mounting
02

Mounting

Match the ceiling or structure before comparing appearance.

  • Recessed / lay-in
  • Surface / suspended
  • Track / high bay
03

Ingress protection

Use the installed exposure and cleaning procedure to set the boundary.

  • Indoor dry-location configurations
  • IP-rated damp or dusty conditions
  • Application-specific review beyond IP65
04

Dimming interface

Coordinate the luminaire with the control narrative and commissioning scope.

  • 0-10V analog dimming
  • DALI-2 addressed control
  • Switched or sensor-integrated operation

Evidence to collect before release

A product name alone is not enough to reproduce a lighting result. Keep each file and parameter tied to the exact configuration under review.

Photometric file packageExact IES/LDT revision, optic, output and CCTElectrical interface recordDriver current, power factor, THD and dimming protocolCompliance document setProduct-level UL, CE or RoHS evidence where applicableThermal and lifetime conditionsAmbient boundary, LM-80/TM-21 context and stated L70 basis

A five-minute screening sequence

  1. Minute 1

    Write the target

    Record task-plane illuminance, visual-comfort objective and operating schedule.

  2. Minute 2

    Fix mounting

    Confirm aperture, ceiling system, suspension or structural attachment.

  3. Minute 3

    Apply environment limits

    Set IP, ambient temperature, impact and cleaning requirements.

  4. Minute 4

    Match controls

    Name the interface, zoning method, sensor behavior and emergency sequence.

  5. Minute 5

    Verify the file

    Run the exact photometric distribution with documented project assumptions.

Send the four filters

We will organize the inputs into a reviewable commercial-lighting shortlist.

Request Quick Select review
